FloBoss 407 Instruction Manual
Rev 5/00 2-11
2.3 INSTALLATION
Before installing the FloBoss 407 or any of its options or accessories, be sure to read Section 1.3, which
describes installation guidelines.
2.3.1 Installing the FloBoss 407 Unit
CAUTION
Take precautions to make sure the unit is handled properly to prevent equipment
damage, and ensure that personnel are aware of any site hazards.
The FloBoss 407, with or without an integral MVS, can be mounted either on a wall or on a 2-inch
pipestand. When mounting the FloBoss 407 on a wall or panel, fasten with 5/16-inch bolts (8 mm)
through each of the four mounting holes. See Figure 2-2 for outline and mounting dimensions. If the
FloBoss 407 has an integral MVS, refer to Appendix B for outline and mounting dimensions.
To mount the FloBoss 407 on a pipestand, with or without an integral MVS, use the U-bolt mounting
kit supplied (contains 5/16-inch U-bolts). For further information on dimensions, as well as other
specifications, refer to Section 2.6.
NOTE
To prolong hinge life, the FloBoss 407 should be mounted vertically. If it is
necessary to mount the FloBoss 407 horizontally, make sure the hinges are located
on top.
