Emerson Fisher FLOBOSS 407

FloBoss 407 Instruction Manual
3-2 Rev 5/00
Information Section Page Number
Troubleshooting and Repair 3.5 3-29
Analog Input Modules 3.5.1 3-29
Analog Output Modules 3.5.2 3-30
Discrete Input Source Module 3.5.3 3-32
Discrete Input Isolated Module 3.5.4 3-32
Discrete Output Source Module 3.5.5 3-33
Discrete Output Isolated Module 3.5.6 3-33
Discrete Output Relay Module 3.5.7 3-33
Pulse Input Source and Isolated Modules 3.5.8 3-34
Slow Pulse Input Source Module 3.5.9 3-34
Slow Pulse Input Isolated Module 3.5.10 3-35
Low-Level Pulse Input Module 3.5.11 3-35
RTD Input Module 3.5.12 3-36
HART Interface Module 3.5.13 3-36
Removal, Addition, and Replacement Procedures 3.6 3-37
Impact on I/O Point Configuration 3.6.1 3-37
Removing/Installing an I/O Module 3.6.2 3-38
I/O Module Specifications 3.7 3-40
3.2 PRODUCT DESCRIPTIONS
The I/O modules plug into the I/O module sockets and accommodate a wide range of process inputs and
outputs. Units used in Measurement/Industry Canada installations must not employ I/O modules
for flow measurement. The following modules are available:
♦ AI Loop
♦ AI Differential
♦ AI Source
♦ AO Source
♦ DI Source
♦ DI Isolated
♦ DO Source
♦ DO Isolated
♦ DO Relay
♦ PI Source
♦ PI Isolated
♦ Slow Pulse Input Source
♦ Slow Pulse Input Isolated
♦ Low-Level Pulse Input
♦ RTD Input
♦ HART
®
Interface
