FloBoss 407 Instruction Manual
Rev 5/00 5-5
Table 5-1. Definition of the Keypad Functions
KEY NORMAL MODE EDIT MODE ALT MODE
I/O
SUMMARY
Displays the following for each I/O
point:
Tag Current Value
Alarm Code
Displays Digit ‘7’
on LCD for data
entry.
I/O DETAIL
Displays the entire set
of parameters for the
I/O point selected.
FLOW
RATES
Displays the following for a
selected meter run:
MCF Today
MCF Yesterday
MCF/Day (Current Flow Rate)
MMBTU/Day (Current BTU Rate)
Meter Input
Static Pressure
Temperature
Displays digit ‘8’
on LCD for data
entry.
COMM PORTS
Displays the
following for selected
communication port:
Baud Rate
Stop Bits
Data Bits
Parity
Status
Mode
Key-on Delay
Key-off Delay
Retry Count
Retry Time
Alarm Pointer
Recv Counter Copy
Retry Counter
Valid Receive Ctr
