FloBoss 407 Instruction Manual
Rev 5/00 3-49
Common Specifications
INPUT
SURGE
WITHSTAND
VIBRATION
MECHANICAL
SHOCK
Scaling Resistor (Rs)
: 10 ohm
supplied (see Input Current
equation to compute other value).
Frequency Response:
0 to 12
KHz maximum, 50% duty cycle.
Input Filter
: Single-pole low-pass,
10 microsecond time constant.
Meets IEEE 472/ANSI C37.90a.
20 Gs peak or 0.06 in. double
amplitude, 10 to 2,000 Hz, per MIL-
STD-202 method 204 condition F.
1500 Gs 0.5 mS half sine per MIL-
STD-202, method 213, condition F.
WEIGHT
CASE
ENVIRONMENTAL
APPROVALS
1.3 ounces (37 grams).
Solvent-resistant thermoplastic
polyester, meets UL94V-0.
Dimensions are 0.60 in. D by
1.27 in. H by 1.69 in. W (15 mm
by 32 mm by 43 mm), not
including pins.
Meets the Environmental
specifications of the ROC or
FloBoss in which the module is
installed, including Temperature
and Transient Protection
specifications.
Approved by CSA for haz-
ardous locations Class I, Divi-
sion 2, Groups A, B, C, and D.
