Common Specifications
INPUT
VIBRATION
MECHANICAL
SHOCK
Loop Resistance (Rl)
: 4.5 kilohm
maximum for best efficiency.
Scaling Resistor (Rs)
: 10 ohm
supplied (see equation above to
compute other value).
Frequency Response:
0 to 10 Hz
maximum, 50% duty cycle.
Input Filter (Debounce):
50
milliseconds (determined by input
reading frequency).
20 Gs peak or 0.06 in. double
amplitude, 10 to 2,000 Hz, per
MIL-STD-202 method 204
condition F.
1500 Gs 0.5 ms half sine per MIL-
STD-202 method 213, condition F.
WEIGHT
CASE
ENVIRONMENTAL
APPROVALS
1.3 ounces (37 grams).
Solvent-resistant thermoplastic
polyester, meets UL94V-0.
Dimensions 0.6 in. D by 1.265
in. H by 1.690 in. W (15 mm by
32 mm by 43 mm), not including
pins.
Meets the Environmental specifi-
cations of the ROC or FloBoss in
which the module is installed,
including Temperature and
Transient Protection
specifications.
Approved by CSA for hazardous
locations Class I, Division 2,
Groups A, B, C, and D.
3.7.9 Pulse Input Module—Low Level
Specifications
MODULE
RACK
TERMINALS
INPUT
A:
Not used
B:
Positive pulse input
C:
Negative pulse input
Type:
Two-state, voltage-pulse
sense.
Active Range:
30 mV minimum to
3 V maximum, peak-to-peak.
Frequency Response:
0 to 3 kHz,
50% duty cycle.
Impedance
: 500 kilohms.
POWER
REQUIREMENTS
INPUT
ISOLATION
4.9 to 5.1 Vdc, 2 mA maximum
(supplied by ROC or FloBoss).
Insulation:
10 megohm
minimum, input or output to
case.
Voltage:
4,000 Vac (RMS)
minimum, input to output.
Capacitance:
6 pF typical, input
to output.
