FloBoss 407 Instruction Manual
3-54 Rev 5/00
3.7.11 HART Interface Module
Specifications
FIELD WIRING
TERMINALS
CHANNELS
HART
MODULES AND
DEVICES
SUPPORTED
LOOP POWER
POWER
REQUIREMENTS
A:
Loop Power (+T)
B:
Channel 1 (CH1)
C:
Channel 2 (CH2)
2 HART-compatible channels,
which communicate via digital
signals only.
Mode:
Half-duplex.
Data Rate:
1200 BPS
asynchronous.
Parity:
Odd.
Format:
8 bit.
Modulation:
Phase coherent,
frequency shift keyed (FSK) per
Bell 202.
Carrier Frequencies:
Mark 1200
Hz, Space 2200 Hz, ± 0.1%.
Up to 6 HART Modules and 32
HART devices maximum.
Point-to-Point Mode:
2 HART
devices per Module (1 per channel).
Multi-drop Mode:
Up to 10 HART
devices per Module (5 per channel).
Total power supplied through
module for HART devices is 20 mA
per channel at 10 to 29 Vdc. Each
HART device typically uses 4 mA.
Loop Source:
11 to 30 Vdc, 40
mA maximum from ROC/FloBoss
power supply or ROC364 I/O
converter card.
Module:
4.9 to 5.1 Vdc, 17 mA
maximum.
VIBRATION
WEIGHT
MECHANICAL
SHOCK
CASE
ENVIRON-
MENTAL
APPROVALS
20 Gs peak or 0.06 in. double
amplitude, 10 to 2,000 Hz, per
MIL-STD-202 method 204
condition F.
1.7 ounces (48 grams) nominal.
1500 Gs 0.5 mS half sine per
MIL-STD-202, method 213,
condition F.
Solvent-resistant thermoplastic
polyester, meets UL94V-0.
Dimensions 0.60 in. D by 2.00 in.
H by 1.69 in. W (15 mm by 51
mm by 43 mm), not including
pins.
Meets the Environmental specifi-
cations of the ROC or FloBoss
unit in which the module is
installed, including Temperature
and Surge specifications.
Approved by CSA for hazardous
locations Class I, Division 2,
Groups A, B, C, and D.
