Operation of the satellite system
RAXSAT300
113
Controlling the RAXSAT300 cable reel
To control the RAXSAT300 you have the exclusive SAT menu.
• To open the SAT menu press
on the right bar of the status monitor.
Within the SAT menu the following functions can be selected or controlled manually:
Function Description
Toggle between the functions of the left joystick
• To toggle between the functions, press function button.
Activating / Disabling the SAT cruise control
• To activate the SAT cruise control press function button.
• To disable the SAT cruise control press function button again.
• To operate the SAT cruise control, proceed as described in „Using the SAT criuse control“ auf Seite 107.
Centering the insertion unit
• To reset the insertion unit in the home position, press function button.
Resetting the SAT meter counter
• To reset the SAT meter counter, press function button.
Activating / disabling cable reel synchronization between cable reel and SAT cable reel
• To activate the synchronizaton between cable reel and SAT cable reel press function button.
• To disable the synchronization between cable reel and SAT cable reel press function button again.
Setting the maximum speed for the feeder unit
• To activate the maximum feeder speed of the feeder unit press function button.
• Press
.
An input Ƃeld is displayed.
• Enter the maximum feeder speed in percent.
• To conƂrm the input and return to the previous ment press
.
• To cancel the input and return to the previous menu press
.
• To disable the maximum feeder speed of the feeder unit press function button again.
Set the winding length of the SAT cable reel per keypress
• To set the winding length in cm press
.
An input Ƃeld is displayed.
• Enter the distance in cm that is to be wound up or unwound from the SAT cable reel per keypress (from 1 to
100 cm).
• To wind the SAT cable by the set value per keystroke, press
.
• To unwind the SAT cable by the set value per keystroke, press
.
