Functional description
Installation options
24
Installation options
The DCX5000 desktop control unit is designed to be built into vehicles. The control panels can either be arranged at your work place in a compact
manner or customized as desired. There are three installation options:
DCX5000 with frame bezel plate
Control panels and touch-screen monitor are integrated in a frame bezel plate which can be mounted on the workbench. The touch-screen monitor
can be tilted at different angles.
1
2
3
3
1 Bezel plate for control panels
2 Touch-screen monitor
3 Control panels
