Envirosight DCX5000 User Manual

Technical data
Desktop Control Unit DCX5000
119
Technical data
Desktop Control Unit DCX5000
Features
Two 3-axis-joysticks with push-function to control the crawler and all
camera functions incl. zoom
Touch-screen for status display and system operation
(optional) frame for compact arrangement of operating components
at the work place
Monitor
Diagonal screen size 10.4 inch
Resolution 800 x 600
Interfaces Connection control unit CCU1
Power supply through control unit CCU1
Storage ---
Video format ---
Supported image formats ---
Protection class IPX0 (protect from humidity and moisture, not suitable for
outdoors)
Ambient conditions
Ambient temperature range 0° C - 40° C
Storage temperature range 0° C - 40° C
Material Aluminum / glass / plastic
Dimensions (L x W x H) approx. 800 mm x 400 mm x 120 mm
Weight
(incl. frame for compact arrangement)
approx. 10 kg

Envirosight DCX5000 Specifications

General

Brand	Envirosight
Model	DCX5000
Category	Controller
Language	English
