Operation of the system
Touch-screen monitor
40
Help menu
The help menu is available in all submenus and provides information on functions or buttons.
The symbol for the help menu
is always located in the lower left-hand corner.
Navigating in submenus
If you are in a submenu of a main function or a system component (with the exception of the main function) the left hand keypad is inactive and
on the right hand keypad navigation keys are being displayed.
2341
1 Arrow key left
2 Arrow key right
3 Back button (one level back)
4 Main menu button (changes directly to the main menu level)
• For navigating between the submenu pages press the arrow keys.
• For navigating one step back, press
.
• For returning to the next higher main menu level press
.
If the options available in the submenus are to be found on several pages this is indicated by points at the bottom edge of the context window.
The highlighted point shows which page you are currently on.
