Functional description
Application possibilities
19
LED display CCUI
The ON/OFF button is framed by a round LED. The LED is divided into four different sectors.
Depending on the system status these sectors with the respective symbols light up.
Symbol / segment Description
LED display lights up in this segment when
– power is supplied to the system
– the system was shut down.
LED display lights up in this segment, when the system in in operation.
LED display lights up in this segment, while the system is shutting down.
LED display lights up in this segment, while the system is booting and initializing.
