Functional description
DAshboard
30
Main functions
At the left side of the screen display the main functions dashboard, system settings, diagnosis and help are located.
Dashboard
The dashboard corresponds to the main inspection screen and serves to check the status indicators and monitor all functions of connected system
components during inspection. When selecting the menu item dashboard the status indicators are displayed in the context window.
System settings
In the system settings all settings with regard to text displays, system time or network settings can be made.
Diagnosis
This dialog shows, which devices are connected and further information. This information is mainly required for service purposes.
Help
The help options displayed in this dialog refer to the respective menu that has been selected.
