Operation of the system
Left control panel
36
Left control panel
Camera movement
• Set the camera to the home position (0° panning and 0° rotation) by pressing the joystick button of the left joystick.
• Move the joystick forwards / backwards to turn the camera upwards / downwards.
• Move the joystick to the left / to the right to make the camera rotate.
• For a faster camera movement continue to push the joystick to the left / to the right.
• If you wish to keep the current camera position release the joystick.
Zoom
By turning the joystick you can enlarge or minimize the picture detail.
• For enlarging the picture detail turn the joystick counterclockwise.
• For minimizing the picture detail turn the joystick clockwise.
Light intensity of the camera light
With the lowest control encoder wheel on the control panel of the left joystick the intensity of the camera light can be changed.
Up to the 20 percent mark the intensity is increased in percentage steps. One encoder wheel step corresponds to 1%.
At a light intensity of more than 20 % one encoder wheel step corresponds to 5 %.
The LED bars on the control panel as well as the dashboard show the change of the light intensity in 20 % steps.
• For increasing the light intensity, turn the encoder wheel forwards.
• For reducing the light intensity, turn the encoder wheel backwards.
