Functional description
Control elements
20
Contr
ol elements
Contr
ol panel right side (crawler control)
1
freely programmable buttons
2
Switching between automatic / manual cable reel operation
3
Clutch on / off
4
Backeye
camera
5
Crawler speed control
6
Cable reel speed control
7
Reel tension control
8
3-axis joystick with push-function
1
2
3
4
5
8
7
6
19
21
