Operation of the satellite system
RX140SAT II
106
Controlling the SAT camera / Feeder unit
Toggle the functions using the function button for the left joystick until the SAT camera icon lights up green .
OR
Double-click the left joystick button until the icon for the SAT camera lights up green.
Pull the joystick backwards / push the joystick forwards to move the SAT camera upwards / downwards.
Push the left joystick to the left / to the right to make the SAT camera rotate.
Press the joystick button to reset the SAT camera to the home position (center position).
To unwind the SAT camera cable, turn the left joystick on the Z axis to the right.
To wind up the SAT camera cable, turn the left joystick on the Z axis to the left.
NOTE!
The further the joystick is moved in the corresponding direction the higher the feed speed will be. A quarter turn of the joystick
corresponds to approximately 25% of the maximum feed speed.
Controlling the insertion unit / feeder unit
Toggle the functions using the function button for the left joystick until the insertion unit icon lights up green .
OR
Double-click the left joystick button until the icon for the insertion unit lights up green.
CAUTION!
Danger of damage to the crawler and the insertion unit
The home position function must not be activated during an inspection.
This may result in severe damages of the system
The movement can be stopped by pressing the right joystick button.
NOTE!
The insertion unit can be reset into the center position (home position) only by pushing
.
To activate the functions and the operation of the insertion unit, press repeatedly in succession until the insertion unit is selected.
Insertion unit icon is highlighted in green.
Pull the joystick backwards / push the joystick forwards to move the insertion unit upwards / downwards.
Push the left joystick to the left / to the right to make the insertion unit rotate.
OR
Double-click the left joystick button until the function is active.
• Press
to reset the SAT camera to the home position (center position).
To unwind the SAT camera cable, turn the left joystick on the Z axis to the right.
To wind up the SAT camera cable, turn the left joystick on the Z axis to the left.
