DISASSEMBLY & ASSEMBLY Disassembly Flowchart 67
Confidential
INK SYSTEM MECHANISM
“3.4.3.14 LEFT COVER ASSY
(p86)”
Start
“3.4.3.1 PRINTER COVER (p72)”
“3.4.3.3 RIGHT HOUSING PLATE
(p74)”
“3.4.3.2 LEFT HOUSING PLATE
(p73)”
“3.4.3.6 REAR COVER SUB ASSY
(p77)”
“3.4.3.7 REAR COVER (p79)”
“3.4.3.17 RIGHT IC COVER
SENSOR (p91)”
“3.4.5.14 BUFFR ASSY (p151)”
“3.4.3.15 RIGHT HOUSING CAP /
RIGHT COVER ASSY (p88)”
“3.4.3.13 RIGHT IH COVER
(p85)”
“3.4.5.17 RIGHT INK HOLDER
ASSY (p161)”
“3.4.3.16 LEFT IC COVER
SENSOR (p90)”
“3.4.3.12 LEFT IH COVER (p84)”
“3.4.5.16 LEFT INK HOLDER
ASSY (p156)”
“3.4.2.1 POROUS PAD (p70)”
“3.4.5.18 INK EJ ASSY (p165)”
“3.4.5.15 CIRCULATION PUMP
ASSY (p153)”
“3.4.5.13 DUCT TUBE ASSY
(p150)”
“3.4.1.1 Unlocking the CR UNIT
(p69)”
“3.4.5.11 PUMP CAP ASSY
(p143)”
“3.4.5.12 CLOTH WIPER
CARRIAGE ASSY (p146)”
“3.4.2.2 WIPER UNIT (p70)”
“3.4.3.16 LEFT IC COVER
SENSOR (p90)”
“3.4.3.12 LEFT IH COVER (p84)”
“3.4.3.4 PANEL ASSY (p75)”
“3.4.1.1 Unlocking the CR UNIT
(p69)”
“3.4.5.11 PUMP CAP ASSY
(p143)”
“3.4.4.4 POWER SUPPLY BOARD
(p99)”
“3.4.5.1 CR COVER (p103)”
“3.4.5.2 DAMPER KIT (p104)”
“3.4.5.8 TUBE ASSY (p132)”
“3.4.3.17 RIGHT IC COVER
SENSOR (p91)”
“3.4.3.13 RIGHT IH COVER
(p85)”
