Booster power supply configuration
Set DIP switches SW 2-6 to On. This configures the booster supply’s Trouble
relay to close only on loss of AC power. All other booster troubles are signaled
through the sense circuits.
Note: In Figure 31, the booster supply is configured so that Sense 1 controls all
four NACs. For DIP switch settings for this and other booster supply
configurations, refer to the technical documentation received with the booster
supply.
Signature modules configuration
Configure the SIGA-CC1 and SIGA-CT1 modules as shown below.
Properties
-CC1 Device Type = SUPERVISEDOUTPUT
Personality code 5: signal - supervised output (Class B)
Text 1 = REMOTE_SUPPLY
Text 2 = SENSE_1
-CT1 Model = CT1
Device Type = ACFAIL
Personality code 3: active - NO nonlatching (Class B)
Text 1 = REMOTE_SUPPLY
Text 2 = AC_FAILURE
