Multimeter Tests
150 MAX-635G
Stressed Balance
Result displays the measurement value for Stressed Balance and
pass/fail status dependent on the Good/Marginal Balance threshold
settings.
Test Status displays the current state of measurement or an error
message.
To select the Stressed Balance parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
Threshold Settings
The Threshold Settings page allows you to set the
Good/Marginal Balance threshold values for the
Stressed Balance test. The threshold is a
programmable value you can use as an on-screen
indicator in each test when a measured value is too
high or too low.
Type is the threshold limit and is fixed to
Maximum.
Enabled is a flag to use the current threshold:
either Yes or No.
Note: Disabling Good Balance will also disable the
Marginal Balance threshold, even if you Enabled it.
