SmartR™ Features
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 169
FaultMapper
Resistance read-only entry is a value for the resistance constant of the
cable.
Cable Length allows you to set the length of the cable for more
accurate results.
Cable Temperature allows you to change the temperature of the cable
under test in either °F or °C.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
TDR
The FaultMapper TDR function provides a shortcut to
the TDR test. A dialogue box opens, warning that you
are about to leave the FaultMapper test. TDR results
captured while running FaultMapper will be available
upon loading TDR. Please go to TDR on page 253 for
information on this test.
