Noise Tests
204 MAX-635G
NEXT
 Zoom references the middle of the x/y axis and not the cursor
position. Press the arrow keys as follows:
Right = x-axis zoom in.
Left = x-axis zoom out.
Up = y-axis zoom in.
Down = y-axis zoom out.
 Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
 1:1 resets the x-axis and y-axis limits to full scale.
 Return To Test removes these function keys and displays the
Spectrum page.
 Result displays the pass/fail status, and test results in graphical format.
 Good is the good threshold value for the selected bandwidth,
represented by a horizontal green line.
 Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
