Frequency Tests
230 MAX-635G
Return Loss
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
Single Frequency Result Details
The Results Details read-only page displays the
pass/fail status, Return Loss and Frequency (TX)
values.
