Frequency Tests
232 MAX-635G
Return Loss
Up = y-axis zoom in.
Down = y-axis zoom out.
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the
Detection page.
Result displays the pass/fail status and a graph of the Return Loss
Sweep compared to Marginal results. If the measurement is
greater/less than the marginal test threshold, represented by a
horizontal red line, the status is fail. Otherwise, the status is pass.
Test Status displays the current state of measurement or an error
message.
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
