Frequency Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 249
RX Tone with FED
ADSL1/2+: 25, 69, 90, 110, 138, 300, 550, 800, 1104, 2208 kHz
VDSL2-12: 25, 138, 276, 3000, 3750, 5200, 8500, 12000 kHz
WB 5 Tone: 196, 392, 772, 1100, 2200 kHz
Select Graph button changes to Graph Selected when pressed and
opens a new selection of function keys which allow you to maneuver
the graph as follows:
Cursor - press the left/right arrow keys to decrease/increase the
values by moving the cursor. Press and hold the left/right arrow
keys to accelerate the cursor. Press to recall the cursor and
place it in the middle of the current x-axis limits.
Zoom references the middle of the x/y axis and not the cursor
position. Press the arrow keys as follows:
Right = x-axis zoom in.
Left = x-axis zoom out.
Up = y-axis zoom in.
Down = y-axis zoom out.
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the test
page.
Result displays the values for both the RX VF/WB Loss and Frequency.
Test Status displays the current state of measurement or an error
message.
