TDR
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 277
Result Details
Note: The saved TDR test only displays the live/primary trace.
Landscape Mode generates the following function keys:
Portrait Mode is used to change the screen orientation from
landscape to portrait.
Select Graph opens a new selection of function keys which allow
you to maneuver the graph. (Same as above.)
Parameters displays a small strip window listing the following
values: Range, Gain, Pulse Width, and Current Trace (not in Auto
TDR). They can be edited or viewed the same way as in Portrait
Mode (described above), dependent on the TDR test being run.
Cable Setup displays a small strip window when selected allowing
you to view the Cable Type, Cable Fill, VOP, and Cable
Temperature. For more information, see Cable Setup in portrait
mode.
To select the parameter values in Landscape Mode:
1. Press the desired function key.
2. For Parameters and Cable Setup, press the up/down arrow keys to
highlight the desired parameter.
3. Press the left/right arrow keys to view, select the options, or
increase/decrease values.
4. Press to confirm the value.
