Copper Auto Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 311
User Auto Test
Up = y-axis zoom in.
Down = y-axis zoom out.
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys to display the
previous function keys.
Landscape Mode function key allows you to view the WB PSD Noise
results in landscape mode. Whether the keyboard is on the right or left
is dependent on your preferred Landscape Mode Settings configured
in Application Settings/General.
Frequency Result
The Frequency Result page displays results and
pass/fail status for the VF/AC Balance test.
