Setting Up DSL/IP Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 357
Test Setup
Traceroute Test Setup
The Traceroute Test Setup tab allows you to configure
the following parameters:
Address Format is URL or IP Address.
Destination Address is the destination IP or URL
address.
Max Hops specifies the maximum number of
hops (1 to 32) used in attempting to reach the
destination address.
Timeout is the time in seconds from 1 to 10, that
the unit will wait for a response back from the
destination device.
To configure test setup values:
1. Press the up/down arrow keys to select the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
5. If you make any changes to the parameter values, press the on-screen
function keys to save or cancel your input.
