Setting Up Copper Tests
Copper and G.fast/VDSL2/ADSL2+ Multi-play Test Set 75
Cable Book
Capacitance T/R to GND/A/B to E specifies a value for the capacitance
per length to ground constant.
Resistance specifies a value for the resistance constant of the cable.
Attenuation @ 300 kHz specifies a value for the reduction in signal
strength or insertion loss of the cable.
VOP is the velocity of propagation for the cable defined in m/μsec
(meters per microsecond), and as a ratio and percentage of the speed
of light.
Temperature specifies the temperature of reference at which all cable
parameters have been measured, in either F (Fahrenheit) or C
(Celsius) units. The measurement units are updated based on the
Temperature settings in Setup/Application Settings/Standard.
To view and modify the cable details:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options and use the navigation
keys to scroll through.
4. Press to confirm the value.
5. Press the Accept function key to update the cable details with your
changes.
