Programmer’s Guide, cont’d
CrossPoint / MAV Matrix Switchers • Programmer’s Guide
4-18
Command ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
Lock (executive) modes
N
See “Setting the front panel locks (Executive modes)” in chapter 3, “Operation”, for more information on the Lock
modes.
Lock all front panel functions 1X
Exe1
]
Enable Lock mode 1.
Lock advanced front panel
functions
2X
Exe2
]
Enable Lock mode 2.
Unlock all front panel
functions
0X
Exe0
]
Enable Lock mode 0.
View lock status X
X$]
Resets
Reset global presets and names
E
ZG
}
Zpg
]
Clear all global presets and
their names.
Reset one global preset
EX(
ZG
}
Zpg
X(]
Clear global preset
X(
.
Reset RGB delays
E
ZD
}
Zpd
]
Reset all RGB delays to 0.0
seconds.
Reset audio input levels
E
ZA
}
Zpa
]
Reset all audio input levels
(gain and attenuation) to 0 dB.
Reset audio output levels
E
ZV
}
Zpv
]
Reset all audio output
levels (volume) to 100% (no
attenuation).
Reset all mutes
E
ZZ
}
Zpz
]
Reset all audio or RS-232
mutes.
Reset room map
E
ZR
}
Zpr
]
Clear all room definitions.
Reset individual room
EX1)
ZR
}
Zpr
X1)]
Delete room
X1)
.
Reset all room presets and
names
E
ZP
}
Zpp
]
Clear all room presets and
names.
Reset individual room preset
and name
EX1)
*
X(
ZP
}
Zpp
X1)
*
X(]
Clear an individual room
preset and name.
Reset whole switcher
E
ZXXX
}
Zpx
]
Clear all ties and presets,
reset all audio gains to 0 dB,
and reset volume to 100%.
Absolute reset
E
ZQQQ
}
Zpq
]
Similar to Reset whole
switcher, plus clear the IP
address to 192.168.254.254
and subnet mask to
255.255.000.000.
N
X$
= Lock mode 0, 1 or 2
X(
= Global or room preset # 00 - 32, 10 maximum for a room preset (00 = current configuration)
X1)
= Room # (for room presets) 10 max. (Each can have up to 10 presets (
X(
s) assigned.)
Command/response table for SIS commands (continued)
