315
www.factoryfive.com 508-291-3443
Push plastic bushings into both sides of the hatch frame hinge bracket. Use a vise to push them in
evenly if necessary.
Insert the bronze bushings into the frame mounts on the roll bar.
From the inside of the rollbar, attach the frame side hatch hinge arm using the shoulder bolt and
5
/
16
” lock
nut. Tighten the lock nut so that it will rotate freely but does not allow any side to side movement.
