2. Assembly
2−33
Festo P.BE−CPX−SYS−EN en 0902e
2. For CPX terminals with 4 or more interlinking blocks: you
will require additional mounting brackets of type
CPX−(M−)BG−RW−... every 100 or150 mm. These are ready−
fitted on delivery.
3. For CPX terminals with MPA pneumatics:
Check whether you need additional wall supports for the
pneumatics module (see MPA pneumatics manual).
For CPX terminals with Midi/Maxi
pneumatics:
Make sure that the spacer rings have been fitted (see
above in this section).
4. Configure the CPX terminal as follows (see also Tab.2/5
and Tab.2/6):
Any mounting position
Two screws at each of the end plates
Screws on the additional mounting elements of type
CPX−(M−)BG−RW−...
2 or 3screws on the pneumatic interface
Make sure there
is sufficient space for connecting the power
supply cables and tubing and for heat dissipation.
