19.7 Moving measurement tools
Procedure
Follow this procedure to move a measurement tool:
Push the Measure button.1
On the menu, select Advanced. This will display the measurement menu.2
Select the toolbar button. This will display a menu listing all currently
active measurement tools.
3
On the menu, select the measurement tool that you wish to move. This will
display a submenu.
4
On the submenu, select Move and push the joystick. This will make the
measurement tool turn blue. You can now move the measurement tool using
the joystick.
5
94 Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010
19 – Working with measurement tools and isotherms
