20.1 Adding a digital photo
General
When you save an infrared image you can also add a digital photo of the object of
interest. This digital photo will automatically be associated with the infrared image,
which will simplify post-processing and reporting in, for example, FLIR Reporter.
Procedure
Follow this procedure to take a digital photo:
To preview an image, push Preview/Save button. This will display the doc-
umentation toolbar.
1
On the documentation toolbar, select the toolbar button and push the
joystick.
2
Do one of the following:
■
To take the digital photo, push the Preview/Save button.
■
To go back to infrared mode, push the joystick
3
Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 99
20 – Annotating images
