17 Working with fusion
What is fusion?
Fusion is a function that lets you display part of a digital photo as an infrared image.
For example, you can set the camera to display all areas of an image that have a
certain temperature in infrared, with all other areas displayed as a digital photo. You
can also set the camera to display an infrared image frame on top of a digital photo.
You can then move around the infrared image frame, or change the size of the image
frame.
Fusion types
Depending on camera model, up to four different types of fusion are available. These
are:
■
Above: All areas in the digital photo with a temperature above the specified tem-
perature level are displayed in infrared.
■
Below: All areas in the digital photo with a temperature below the specified tem-
perature level are displayed in infrared.
■
Interval: All areas in the digital photo with a temperature between two specified
temperature levels are displayed in infrared.
■
Picture in Picture: An infrared image frame is displayed on top of the digital
photo.
80 Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010
