24 Pin configurations

Pin configuration

for USB Mini-B

connector

10763203;a1

ConfigurationPin

+5 V (out)1

USB –2

USB +3

N/C4

Ground5

Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 113
