15.10 Removing an additional infrared lens
NOTE
Do not touch the lens surface when you remove an infrared lens. If this happens,
clean the lens according to the instructions in section 22.2 – Infrared lens on
page 111.
■
■
When you have removed the lens, put the lens caps on the lens immediately, to
protect it from dust and fingerprints.
Procedure
Follow this procedure to remove an additional infrared lens:
Push the lens release button to unlock the lens.
10764603;a1
1
Rotate the lens counter-clockwise 30° (looking at the front of the lens).
10764703;a1
2
Carefully pull out the lens from the bayonet ring.
10764803;a1
3
Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 57
15 – Handling the camera
