15.12
Using
the
laser
pointer
Figure
10760303;a1
Procedure
Follow
this
procedure
to
use
the
laser
pointer:
T
o
turn
on
the
laser
pointer
,
push
and
hold
the
laser
pointer
button.
1
T
o
turn
off
the
laser
pointer
,
release
the
laser
pointer
button.
2
NOTE
The
laser
pointer
may
not
be
enabled
in
all
markets.
Publ.
No.
1558792
Rev
.
a460
–
ENGLISH
(EN)
–
July
1,
2010
61
