FLIR T Series User Manual

20.5 Adding a sketch
General
A sketch is freehand drawing that you create in a sketch work area separate from
the infrared image using the stylus pen. You can use the sketch feature to create a
simple drawing, write down comments, dimensions, etc.
Procedure
Follow this procedure to add a sketch:
To preview an infrared image, push the Preview/Save button.1
On the documentation toolbar, select the toolbar button, using the
stylus pen. This will display the sketch work area.
For information about the work area, see section 10.1.3 – Sketch work area
on page 23.
2
In the sketch work area, draw your sketch using the stylus pen. You can
change pen color, and erase your sketch using the eraser.
3
To confirm your sketch and leave the sketch work area, select OK.4
On the documentation toolbar, select Save and push the joystick.5
Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 105
20 – Annotating images
