Procedure
Follow this procedure to add a text annotation:
To preview an image, push the Preview/Save button. This will display the
documentation toolbar.
1
Move the joystick left to select the text annotation toolbar button.
2
Push the joystick to display the text annotation and image description work
area. If the SD Memory Card contains a valid *.tcf file, the text annotation
labels will be displayed as a list.
For information about the work area, see section 10.1.4 – Text annotation
and image description work area on page 25.
3
Move the joystick up/down to select a text annotation label.4
Push the joystick. This will display a submenu listing all available text anno-
tation values for that label.
5
On the submenu, move the joystick up/down to select the value you want
to use. You can also select the keyboard button at the bottom of the sub-
menu if you want to create a value from scratch.
6
Push the joystick. This will close the submenu, and the value you selected
will now be displayed to the right of the text annotation label.
7
Repeat Steps 4 to 7 for any other text annotation labels that you want to
include in your text annotation.
8
Select the OK button at the bottom of the screen and push the joystick.9
On the documentation toolbar, select Save and push the joystick. The text
annotation is now saved in the image file.
10
Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 103
20 – Annotating images
