Structural
drawing
Rain
hits
the
façade
at
an
angle
and
penetrates
the
plaster
through
cracks.
The
water
then
follows
the
inside
of
the
plaster
and
leads
to
frost
erosion.
10554503;a2
Rain
splashes
on
the
façade
and
penetrates
the
plaster
and
masonry
by
absorption,
which
eventu-
ally
leads
to
frost
erosion.
10554603;a2
Publ.
No.
1558792
Rev
.
a460
–
ENGLISH
(EN)
–
July
1,
2010
