Figure
This figure shows the image description work area:
10765703;a1
Explanation
This table explains the figure above:
OK button
You select this button to confirm and save the text annotation.
1
Tab for the text annotation work area (to select from pre-defined strings)2
Tab for the image description work area (to enter the free text mode, using
the stylus pen)
3
Preview window for the image description4
Keyboard5
Clear button
You select this button to clear all input data from the selected tab.
6
SEE ALSO
For information about adding an image description to an infrared image, see section
20.4 – Adding an image description on page 104.
Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 27
10 – Toolbars and work areas
