Fortinet FortiGate Series Administration Guide

Viewing application, policy, and DLP archive usage data System Status
FortiGate Version 4.0 MR1 Administration Guide
138 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
Figure 50: Top Application Usage table display
To configure the Top Application Usage module - web-based manager
1 Go to System > Status > Usage.
2 Select the Edit icon in the Top Application Usage module title bar.
Figure 51: Configuring the Top Application Usage module
Reset Reset all counts to zero.
Edit Configure module settings.
Refresh Update displayed information.
Close Close the module.
Applications Application names in order of use.
Bytes or
Messages
Traffic volume in bytes or number of messages, depending on Sort Criteria setting.
Sort Criteria Select whether to sort the applications by number of Bytes or number
of Messages.
Report By Select Source Address or Destination Address.
Display User Name Select the check box to show the user name (when known) instead of
the IP address.
Resolve Host Name Select to use reverse-DNS lookup to determine the host name instead
of displaying the IP address.
Reset
Edit
Refresh
Close
