Fortinet FortiGate Series Administration Guide

Schedule groups What’s new in FortiOS Version 4.0 MR1
FortiGate Version 4.0 MR1 Administration Guide
88 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
Schedule groups
You can now create schedule groups, similar to address groups or service groups. In a
firewall policy you can select either an individual schedule or a schedule group.
To create a schedule group - web-based manager
1 Go to Firewall > Schedule > Group and select Create New.
Figure 10: Schedule Group
2 Select OK
auth-pwd
<password>
Enter the user’s password. Maximum 32 characters.
This is available if security-level is auth-priv
or auth-no-priv.
No default.
priv-proto
{aes | des}
Select privacy (encryption) protocol:
aes — CFB128-AES-128 symmetric encryption
des — CBC-DES symmetric encryption
This is available if security-level is
auth-priv.
aes
priv-pwd <key> Enter the privacy encryption key. Maximum 32
characters. This is available if security-level is
auth-priv.
No default.
Variable Description Default
Group Name Enter a name to identify the service group.
Available
Schedules
The list of recurring and one-time schedules available for your group. Use the
arrow buttons to move selected schedules between this list and Members.
Members The list of schedules in the group. Use the arrows to move selected
schedules between this list and Available Services.
