Fortinet FortiGate Series Administration Guide

SNMP System Config
FortiGate Version 4.0 MR1 Administration Guide
242 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
Configuring SNMP
Go to System > Config > SNMP v1/v2c to configure the SNMP agent.
Figure 113: Configuring SNMP
Configuring an SNMP community
An SNMP community is a grouping of devices for network administration purposes. Within
that SNMP community, devices can communicate by sending and receiving traps and
other information. One device can belong to multiple communities, such as one
administrator terminal monitoring both a firewall SNMP community and a printer SNMP
community.
Add SNMP communities to your FortiGate unit so that SNMP managers can connect to
view system information and receive SNMP traps.
You can add up to three SNMP communities. Each community can have a different
configuration for SNMP queries and traps. Each community can be configured to monitor
the FortiGate unit for a different set of events. You can also add the IP addresses of up to
8 SNMP managers to each community.
SNMP Agent Enable the FortiGate SNMP agent.
Description Enter descriptive information about the FortiGate unit. The description can be
up to 35 characters long.
Location Enter the physical location of the FortiGate unit. The system location
description can be up to 35 characters long.
Contact Enter the contact information for the person responsible for this FortiGate
unit. The contact information can be up to 35 characters.
Apply Save changes made to the description, location, and contact information.
Create New Select Create New to add a new SNMP community.
See “Configuring an SNMP community” on page 242.
Communities The list of SNMP communities added to the FortiGate configuration. You can
add up to 3 communities.
Name The name of the SNMP community.
Queries The status of SNMP queries for each SNMP community. The query status
can be enabled or disabled.
Traps The status of SNMP traps for each SNMP community. The trap status can be
enabled or disabled.
Enable Select Enable to activate an SNMP community.
Delete icon Select Delete to remove an SNMP community.
Edit/View icon Select to view or modify an SNMP community.
