Fortinet FortiGate Series Administration Guide

System Maintenance Adding VDOM Licenses
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 333
http://docs.fortinet.com/ • Feedback
To add a firewall policy to the FortiGate NAT device
1 Go to Firewall > Policy.
2 Select Create New.
3 Configure the external to internal firewall policy.
4 Select OK.
Verify that push updates to the FortiGate unit on the internal network are working by going
to System > Maintenance > FortiGuard and selecting Test Availability under Web Filtering
and AntiSpam Options. The Push Update indicator should change to green.
Adding VDOM Licenses
If you have you can increase the maximum number of VDOMs on your FortiGate unit you
can purchase a license key from Fortinet to increase the maximum number of VDOMs to
25, 50, 100 or 250. By default, FortiGate units support a maximum of 10 VDOMs.
The license key is a 32-character string supplied by Fortinet. Fortinet requires the serial
number of the FortiGate unit to generate the license key.
The license key is entered in System > Maintenance > License in the Input License Key
field. This appears only on high-end FortiGate models.
Figure 176: License key for additional VDOMs
Source Interface/Zone Select the name of the interface that connects to the Internet.
Source Address Select All
Destination
Interface/Zone
Select the name of the interface of the NAT device that connects to
the internal network.
Destination Address Select the virtual IP added to the NAT device.
Schedule Select Always.
Service Select ANY.
Action Select Accept.
NAT Select NAT.
Current License The current maximum number of virtual domains.
Input License key Enter the license key supplied by Fortinet and select Apply.
Note: VDOMs created on a registered FortiGate unit are recognized as real devices by any
connected FortiAnalyzer unit. The FortiAnalyzer unit includes VDOMs in its total number of
registered devices. For example, if three FortiGate units are registered on the FortiAnalyzer
unit and they contain a total of four VDOMs, the total number of registered FortiGate units
on the FortiAnalyzer unit is seven. For more information, see the FortiAnalyzer
Administration Guide.
