Fortinet FortiGate Series Administration Guide

Restoring your configuration Managing firmware versions
FortiGate Version 4.0 MR1 Administration Guide
158 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
5 Enter the following command to copy the backed -up configuration file to restore the
file on the FortiGate unit:
execute restore allconfig <name_str> <tftp_ipv4> <passwrd>
Where <name_str> is the name of the backed up configuration file and
<tftp_ipv4> is the IP address of the TFTP server and <passwrd> is the password
you entered when you backed up your configuration settings. For example, if the
backed up configuration file is confall and the IP address of the TFTP server is
192.168.1.168 and the password is ghrffdt123:
execute restore allconfig confall 192.168.1.168 ghrffdt123
The FortiGate unit responds with the message:
This operation will overwrite the current settings and the
system will reboot!
Do you want to continue? (y/n)
6 Type y.
The FortiGate unit uploads the backed up configuration file. After the file uploads, a
message, similar to the following, is displayed:
Getting file confall from tftp server 192.168.1.168
##
Restoring files...
All done. Rebooting...
This may take a few minutes.
Use the CLI show shell command to verify your settings are restored, or log in to the
web-based manager.

Fortinet FortiGate Series Specifications

General

Model	FortiGate Series
Category	Firewall
Throughput	Varies by model
Interfaces	Varies by model
Concurrent Sessions	Varies by model
VPN Support	Yes
High Availability	Yes
Firewall Throughput	Varies by model
VPN Throughput	Varies by model
IPS Throughput	Varies by model
NGFW Throughput	Varies by model
Threat Protection Throughput	Varies by model
New Sessions per Second	Varies by model
Power Supply	Varies by model
Security Features	Firewall, IPS, Application Control, Web Filtering, Antivirus, VPN
Virtual Domains	Yes
Form Factor	Desktop, Rackmount
