Fortinet FortiGate Series Administration Guide

System Config HA
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 237
http://docs.fortinet.com/ • Feedback
To display the cluster members list, log into an operating cluster and go to System >
Config > HA.
Figure 108: Example FortiGate-5001SX cluster members list
If virtual domains are enabled, you can display the cluster members list to view the status
of the operating virtual clusters. The virtual cluster members list shows the status of both
virtual clusters including the virtual domains added to each virtual cluster.
To display the virtual cluster members list for an operating cluster log in as the global
admin administrator and go to System > Config > HA.
Figure 109: Example FortiGate-5001SX virtual cluster members list
View HA Statistics Displays the serial number, status, and monitor information for each cluster
unit. See “Viewing HA statistics” on page 238.
Up and down arrows Changes the order of cluster members in the list. The operation of the
cluster or of the units in the cluster are not affected. All that changes is the
order of the units on the cluster members list.
Disconnect from Cluster
Edit
Download Debug Log
Up and Down
Arrows
Disconnect from Cluster
Up and Down
Arrows
Edit
Download Debug Log
