Fortinet FortiGate Series Administration Guide

System Config SNMP
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 249
http://docs.fortinet.com/ • Feedback
Table 24: FortiGate Virtual domains
MIB field Description
fgVdInfo FortiGate unit Virtual Domain related information.
fgVdNumber The number of virtual domains configured on this FortiGate
unit.
fgVdMaxVdoms The maximum number of virtual domains allowed on the
FortiGate unit as allowed by hardware or licensing.
fgVdEnabled Whether virtual domains are enabled on this FortiGate unit.
fgVdTable.fgV
dEntry
Table of information about each virtual domain—each virtual domain has an
fgVdEntry. Each entry has the following fields.
fgVdEntIndex Internal virtual domain index used to uniquely identify entries
in this table.
This index is also used by other tables referencing a virtual
domain.
fgVdEntName The name of the virtual domain.
fgVdEntOpMode Operation mode of this virtual domain - either NAT or
Transparent.
Table 25: FortiGate Active IP sessions table
MIB field Description
fgIpSessIndex The index number of the IP session within the table
fgIpSessProto The IP protocol the session is using (IP, TCP, UDP, etc.).
fgIpSessFromAddr The source IPv4 address of the active IP session.
fgIpSessFromPort The source port of the active IP session (UDP and TCP only).
fgIpSessToAddr The destination IPv4 address of the active IP session.
fgIpSessToPort The destination port of the active IP session (UDP and TCP only).
fgIpSessExp The number of seconds remaining until the sessions expires (if idle).
fgIpSessVdom Virtual domain the session is part of. Corresponds to the index in fgVdTable.
fgIpSessStatsTable IP Session statistics table for the virtual domain.
fgIpSessNumber Total sessions on this virtual domain.
Table 26: FortiGate Firewall policy statistics table
MIB field Description
fgFwPolicyStatsVdomIndex Index that identifies the virtual domain. This is the same index used
by fgVdTable.
fgFwPolicyID Firewall policy ID.
Only enabled policies are available for querying.
Policy IDs are only unique within a virtual domain.
fgFwPolicyPktCount Number of packets matched to policy (passed or blocked,
depending on policy action). Count is from the time the policy
became active.
fgFwPolicyByteCount Number of bytes matched to policy (passed or blocked, depending
on policy action). Count is from the time the policy became active.
Table 27: FortiGate Dialup VPNs
MIB field Description
fgVpnDialupIndex An index value that uniquely identifies an VPN dial-up peer in the table.
fgVpnDialupGateway The remote gateway IP address on the tunnel.
