Fortinet FortiGate Series Administration Guide

Firewall Service Viewing the predefined service list
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 429
http://docs.fortinet.com/ • Feedback
H323 H.323 multimedia protocol. H.323 is a standard
approved by the International Telecommunication
Union (ITU) defining how audiovisual conferencing
data can be transmitted across networks. For more
information, see the FortiGate Support for H.323
Technical Note.
TCP 1720, 1503
UDP 1719
HTTP Hypertext Transfer Protocol. HTTP is used to
browse web pages on the World Wide Web.
TCP 80
HTTPS HTTP with secure socket layer (SSL). HTTPS is
used for secure communication with web servers.
TCP 443
ICMP_ANY Internet Control Message Protocol. ICMP allows
control messages and error reporting between a
host and gateway (Internet).
ICMP Any
IKE Internet Key Exchange. IKE obtains authenticated
keying material for use with the Internet Security
Association and Key Management Protocol
(ISAKMP) for IPSEC.
UDP 500, 4500
IMAP Internet Message Access Protocol. IMAP is used by
email clients to retrieves email messages from
email servers.
TCP 143
IMAPS IMAP with SSL. IMAPS is used for secure IMAP
communication between email clients and servers.
IMAPS is only available on FortiGate units that
support SSL content scanning and inspection.
TCP 993
INFO_ADDRESS ICMP information request messages. ICMP 17
INFO_REQUEST ICMP address mask request messages. ICMP 15
IRC Internet Relay Chat. IRC allows users to join chat
channels.
TCP 6660-6669
Internet-
Locator-Service
Internet Locator Service. ILS includes LDAP, User
Locator Service, and LDAP over TLS/SSL.
TCP 389
L2TP Layer 2 Tunneling Protocol. L2TP is a PPP-based
tunnel protocol for remote access.
TCP 1701
UDP 1701
LDAP Lightweight Directory Access Protocol. LDAP is
used to access information directories.
TCP 389
MGCP Media Gateway Control Protocol. MGCP is used by
call agents and media gateways in distributed Voice
over IP (VoIP) systems.
UDP 2427, 2727
MS-SQL Microsoft SQL Server is a relational database
management system (RDBMS) produced by
Microsoft. Its primary query languages are MS-SQL
and T-SQL.
TCP 1433, 1434
MYSQL MySQL is a relational database management
system (RDBMS) which runs as a server providing
multi-user access to a number of databases.
TCP 3306
NFS Network File System. NFS allows network users to
mount shared files.
TCP 111, 2049
UDP 111, 2049
NNTP Network News Transport Protocol. NNTP is used to
post, distribute, and retrieve Usenet messages.
TCP 119
NTP Network Time Protocol. NTP synchronizes a host’s
time with a time server.
TCP 123
UDP 123
NetMeeting NetMeeting allows users to teleconference using
the Internet as the transmission medium.
TCP 1720
Table 46: Predefined services (Continued)
Service name Description IP Protocol Port

Fortinet FortiGate Series Specifications

General

Model	FortiGate Series
Category	Firewall
Throughput	Varies by model
Interfaces	Varies by model
Concurrent Sessions	Varies by model
VPN Support	Yes
High Availability	Yes
Firewall Throughput	Varies by model
VPN Throughput	Varies by model
IPS Throughput	Varies by model
NGFW Throughput	Varies by model
Threat Protection Throughput	Varies by model
New Sessions per Second	Varies by model
Power Supply	Varies by model
Security Features	Firewall, IPS, Application Control, Web Filtering, Antivirus, VPN
Virtual Domains	Yes
Form Factor	Desktop, Rackmount
