Fortinet FortiGate Series Administration Guide

Firewall Protection Profile SSL content scanning and inspection
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 483
http://docs.fortinet.com/ • Feedback
While the SSL sessions are being set up, the client and server communicate in clear text
to exchange SSL session keys. The session keys are based on the client and server
certificates. The FortiGate SSL decrypt/encrypt process intercepts these keys and uses a
built-in signing CA certificate named Fortinet_CA_SSLProxy to create keys to send to the
client and the server. This signing CA certificate is used only by the SSL decrypt/encrypt
process. The SSL decrypt/encrypt process then sets up encrypted SSL sessions with the
client and server and uses these keys to decrypt the SSL traffic to apply content scanning
and inspection.
Some client programs (for example, web browsers) can detect this key replacement and
will display a security warning message. The traffic is still encrypted and secure, but the
security warning indicates that a key substitution has occurred.
You can stop these security warnings by importing the signing CA certificate used by the
server into the FortiGate unit SSL content scanning and inspection configuration. Then the
FortiGate unit creates keys that appear to come from the server and not the FortiGate unit.
You can replace the default signing CA certificate, Fortinet_CA_SSLProxy, with another
signing CA certificate. To do this you need the signing CA certificate file, the CA certificate
key file, and the CA certificate password.
All SSL content scanning and inspection uses the same signing CA certificate. If your
FortiGate unit is operating with virtual domains enabled, the same signing CA certificate is
used by all virtual domains.
To add a signing CA certificate for SSL content scanning and inspection
1 Obtain a copy of the signing CA certificate file, the CA certificate key file, and the
password for the CA certificate.
2 Go to System > Certificates > Local Certificates and select Import.
3 Set Type to Certificate.
4 For Certificate file use the Browse button to select the signing CA certificate file.
5 For Key file use the Browse button to select the CA certificate key file.
6 Enter the CA certificate Password.
Figure 275: Importing a signing CA certificate for SSL content scanning and inspection
7 Select OK.
The CA certificate is added to the Local Certificates list. In this example the signing CA
certificate name is Example_CA. This name comes from the certificate file and key file
name. If you want the certificate to have a different name, change these file names.
8 Add the imported signing CA certificate to the SSL content scanning and inspection
configuration. Use the following CLI command if the certificate name is Example_CA.
Note: You can add one signing CA certificate for SSL content scanning and inspection. The
CA certificate key size must be 1024 or 2048 bits. 4096-bit keys are not supported for SSL
content scanning and encryption.

Fortinet FortiGate Series Specifications

General

Model	FortiGate Series
Category	Firewall
Throughput	Varies by model
Interfaces	Varies by model
Concurrent Sessions	Varies by model
VPN Support	Yes
High Availability	Yes
Firewall Throughput	Varies by model
VPN Throughput	Varies by model
IPS Throughput	Varies by model
NGFW Throughput	Varies by model
Threat Protection Throughput	Varies by model
New Sessions per Second	Varies by model
Power Supply	Varies by model
Security Features	Firewall, IPS, Application Control, Web Filtering, Antivirus, VPN
Virtual Domains	Yes
Form Factor	Desktop, Rackmount
