Transporting
139
Controls in detail
Mounting lashing points for load rails
E To install: slide the lashing eye
through a recess in the load rail close
to the load until locking mechanism 1
in the recess engages.
i When you pull locking mechanism 1 out of
the recess, the lashing eye is able to move within
the lashing rail or load rail. Make sure that lock-
ing mechanism 1 is always engaged in a recess.
E Check whether the lashing eye is firmly
in place.
E To remove: pull locking
mechanism 1 upward and pull the
lashing eye through a recess towards
the locking mechanism and out of the
load rail.
It is possible to mount a roof rack if your
vehicle is equipped with securing rails on
the roof.
1 Securing rails
Special mountings (sliding blocks) are
available as accessories. These are avail-
able from any authorized Sprinter Dealer.
G Warning
If the lashing eye is not firmly anchored in the
load rail, the lashing eye may slip or snap out
of the load rail in the event of sudden braking
or an accident.
The load would no longer be secured, which
could result in serious injuries caused by the
load slipping.
For this reason, always check that the lashing
eye is firmly in place whenever you install it.
Carrier systems
G Warning
High roof loads may cause a significant dete-
rioration in handling, steering and braking
characteristics even if the maximum permis-
sible gross vehicle weight or axle loads have
not been exceeded. You could endanger
yourself and others.
Always make sure that loads are distributed
correctly and adapt your driving style in ac-
cordance with the load.
Observe the carrier system manufacturer's
installation instructions. An incorrectly se-
cured carrier system or load could come
loose and fall off and thereby endanger you
and others.
Observe the maximum roof loads
(
e page 293), the maximum axle load and
the maximum load-bearing capacity of the
roof rack. Loads transported on the roof must
always be secured with particular care.
